WOLVERINE 84" DOZER BLADE 9178

• Working / Blade Width: 84 inches (7 feet)

• Operating Weight: ~960 lbs to 1,050 lbs (depending on the exact sub-variant)

• Overall Height: ~27 to 29.89 inches

• Length / Depth: ~36.68 to 37.5 inches

• Swing / Angle Range: ±30° two-way horizontal swing angle

• Tilt Range: ±10° two-way vertical tilt angle

• Hydraulic Requirements: 2,500 – 3,000 PSI rated working pressure (gpm range roughly 10–20 gpm depending on setup)

• Mounting Interface: Universal Skid Steer Quick-Attach (SSQA)

• Key Components: Bolt-on replaceable steel cutting edge, adjustable side skid shoes, and heavy-duty shielded dual cylinders

• Overall Width: 84 inches

• Overall Height: 27.9 inches

• Overall Depth: 33.2 inches

• Product Weight: 658 lbs

• Cutting Edge Thickness: 1/2 inch

• Angle Range: 28° left or right (with built-in spring shocks)

• Mounting Interface: Universal Skid Steer Quick-Attach (SSQA)
